Product Details:
Payment & Shipping Terms:
|
| Packing: | Tube | Model: | Customized |
|---|---|---|---|
| Thickness: | 10mm | Transportation: | Sea, Air |
| Type: | Elevator Parts, Lift Spare Part | Width: | 38mm |
| High Light: | weco elevator products,weco lift products |
||
917B Weco Lift Products 38mm Width Full Height Sensor Relay Output Infrared Barrier
WECO-917B model door sensor was developed since 1998 with more than 20 years histroty same as WECO-917A model light curtain. So that this model safety light curtain has been widely used and purchased because of good price and 10mm thickness and 38mm widthness.
Also has central opening and side opening mode for your better choice.
Specification
| Technical Features | 917B6 | 917B7 | |
| Number of Infra Red Diodes | 17 Diodes | 32Diodes | |
| Response Time | Relay Output | 45ms | 61ms |
| Transistor Output | 21ms | 37ms | |
| Scanning Beams | 94~33 Beams | 154~94 Beams | |
| Infrared Diodes Range | 117.5mm | 58.8mm | |
| The Mimimum Door Opening | ≤20mm | ||
| The Maximum Door Opening | ≥1800mm | ||
| Redundancy (one transimitter shielded after 120s detected absent) | NO | yes | |
| Detecting Range | 0-4000mm | ||
| Operation Temperature | -20℃~+65℃ | ||
| Light Immunity | 100000 Lux | ||
| Protection Level | IP54 | ||
| EMC ( EN12015 EN12016) | General circuit level | ||
| LED Interpretation |
1. Yellow LED and Red LED in Receiver on when blocked or in malfunction. 2. Yellow LED in receiver on and Red LED in receiver off without block. |
||
Packaging & Delivery
1. Prompt deliver at the very day.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
WHAT WE HAVE?
--- Ningbo WECO Optoelectronics CO., LTD. has more than 20 years focus on elevator light curtain manufacturing and trading.
--- Our poducts has been sold to more then 40 countries and areas.
--- Good and fast deliery time. As we have thousands sets light curtain in our stock.
--- Mass production quality and good sales performance make us has big price advantage,
